AC Elite Home 50A 12kW EV Charger | CA

 Best EV Chargers 2024

Rated by CNET

Level 2 Hardwired SAE J1772 ALM & DLB
Specifications

Maximum Output | 12 kW / 50 A · Adjustable 16–50 A
Input Voltage | 208 / 240 V AC
Installation | Hardwired · 70 A Circuit for Full Output
Charging Cable | 25 ft · SAE J1772
Load Management | ALM & DLB Supported · ALM Requires Additional Hardware
User Authentication | App · AutoStart · RFID Card
Enclosure Rating | IP65 / NEMA 4X
Warranty | 3 Years

Description

50A / 12KW FAST HOME CHARGING: Delivers up to 12kW of Level 2 charging power at 240V for faster everyday home charging. Adjust output from 16A to 50A to match your home electrical setup, with a 70A circuit required for full 50A output.

ALM & DLB LOAD MANAGEMENT: Supports both Adaptive Load Management (ALM) and charger-to-charger Dynamic Load Balancing (DLB) for more flexible home energy management. ALM requires compatible additional hardware, while DLB works between chargers without additional hardware.

SAE J1772 WITH 25 FT CABLE: Equipped with an SAE J1772 connector and a 25 ft charging cable for flexible reach across garages and driveways. Designed for convenient everyday charging of J1772-equipped EVs and plug-in hybrids.

SMART APP CONTROL & RFID ACCESS: Start, stop and schedule charging with the Autel Charge App, monitor charging activity, adjust charging current, and schedule sessions around off-peak electricity hours. AutoStart keeps everyday charging simple, while optional RFID card access helps prevent unauthorized use. RFID cards are sold separately.

ALL-WEATHER PROTECTION & 3-YEAR WARRANTY: Built for indoor and outdoor use with an IP65 / NEMA 4X enclosure and an operating temperature range from -40°F to 131°F. Integrated protection includes overcurrent, overvoltage, undervoltage and surge protection, with CSA and ENERGY STAR compliance for added confidence. Backed by a 3-year warranty.

Sale price$712.00 CAD Regular price$889.00 CAD
20% OFF
Save $80 at $1,400+ Save $80 at $1,400+ Save $120 at $2,000+ Save $120 at $2,000+
Autel EV Chargers Official Website Autel EV Chargers Official Website Autel EV Chargers Official Website Autel EV Chargers Official Website Autel EV Chargers Official Website Autel EV Chargers Official Website Autel EV Chargers Official Website Autel EV Chargers Official Website Autel EV Chargers Official Website Autel EV Chargers Official Website Autel EV Chargers Official Website Autel EV Chargers Official Website
  • Free Shipping
  • 30-Day Returns
  • 3-Year Warranty
  • Secure Checkout

Rebates & Charging Rewards

✓ Eligible
View Detail

Québec Est. $112.00 after $600 Écorecharge B.C. rebates available

Roulez Électrique Up to 13¢/kWh ChargeLab 10¢/kWh

Pairs well with
Autel RFID Charge Card - 2 Pack
Autel RFID Charge Card - 2 Pack
$55.90
Total $0.00 CAD
$712.00
20% OFF

MaxiCharger AC Elite EV Charger

Enjoy Fast&Smart Charging with Autel

Lightning-Fast Charging

With a powerful output of up to 50 amps and 12 kW, our EV charger significantly reduces range anxiety by providing up to 78 km (48 miles) of driving range in just one hour of charging. That's up to 9 times faster than Level 1 AC chargers, ensuring your vehicle is always ready for the road, quicker than ever.

Built for Durability and Convenience

Compliant with NEMA 4X standards, ensuring robust performance in harsh outdoor conditions. Plus, the flexible 25 ft cables provide extended reach for hassle-free charging, no matter where you park!

Seamless Connectivity for Anytime Use

Easily connect and configure your charger via Bluetooth, WiFi, Ethernet, RS485, or CAN. Enjoy the flexibility to use the charger anytime, with or without an internet connection!

Charging with Confidence

CSA certified for safety and ENERGY STAR certified for efficiency. Plus, enjoy peace of mind with a 3-year warranty and dedicated technical support.

Flexibility to Fit Your Space

Whether you have a small garage or an open driveway, our flexible product line has a solution for your needs. With a sleek, compact design, we offer both an in-body holster or a separate charging holster to suit the space you have.

Maximize Your Charging Experience with the Autel Charge App!

Pair your MaxiCharger AC Elite with the Autel Charge App for ultimate control over your charging process. Start and stop charging, monitor real-time data, schedule charging sessions, adjust maximum amperage, and much more, all in the app.

Save Money

Schedule charging during off-peak hours with our free mobile app

Clear bills

Charging status, bills, and even CO2 saved—track whatever you want

Add Security

Enable RFID card access to prevent unauthorized use

(RFID cards sold separately*)

Regulating current

Tweak the charging current to fit your needs

Product Support

Product Specifications

Charging

Maximum output
Maximum 12 kW (240 VAC @ 50 A model)
Input rating
208/240 VAC, 60 Hz, single phase @ 16 A, 24 A, 32 A, 40 A, 48 A, 50 A

Connector and Cable

Vehicle connector
SAE J1772
Cable length
25 ft. (7.5 m)

Installation

Installation type
Hardwired
Mounting
Wall-mounted or floor using a pedestal

Connectivity

Connections
Bluetooth, Wi-Fi, Ethernet, CAN, RS485
User authentication
App, AutoStart, RFID card
Advanced features
Adaptive Load Management (ALM); Dynamic Load Balancing (DLB)

Protection

Electrical protection
Overcurrent, overvoltage, undervoltage, integrated surge protection
Operating temperature
-40 to 131 °F (-40 to 55 °C)

Dimensions

Dimensions (H × W × D)
In-body Holster: 13.2” x 7.4” x 3.8” (336 x 187 x 97 mm)
Separate Holster: 13.2” x 7.4” x 3.3” (336 x 187 x 85 mm)
Weight
In-body Holster: 15.4 lbs. (7 kg).
Separate Holster: Hardwired model: about 14.8 lbs. (6.7 kg)/ NEMA plug-in model: about 15.4 lbs. (7 kg)

Model and Warranty

Model number
In-body Holster: Maxi US AC W12
Separate Holster: Maxi US AC W12-H
Warranty
3 years warranty

Certifications & Design Awards

Certifications
Certifications
Design awards
Design awards

Installation

Installation
User Manual Download
For installation instructions, we can help you Learn More
Get An installation Quote

Get An installation Quote

Across North America, Qmerit Charge@Home" installation services deliver the highest levels of safety and quality at competitive pricing.lt starts with an upfront pricing estimate. For most home configurations, all you need to do is give us some information about your layout and electrical panel

(888)272-0090

customerservice@qmerit.com

FAQ

FAQ

What's in the Box

Charging Station
Wall Dock
User Manual
Amperage Labels
Accessories

Featured Video Show.

  • 5 stars: 48 (94%)
  • 4 stars: 2 (4%)
  • 3 stars: 0 (0%)
  • 2 stars: 0 (0%)
  • 1 star: 1 (2%)
E
Eric Tremblay
So easy to install, set up and start charging.

What can I say,

Order received quickly, lots of videos to help with installation and set up.

Electrician loved the room to pass the cables,

Took 10 minutes to set up and start charging.

Really like the software, gives me a good idea of the cost on my electric bill.

Just happy with the charger

V
V.N.
AC Elite Home 50A 12 Kw EV charger

Very good looking charger, easy to handle. App co.es with it's also very useful. I had an issue with wifi connectivity ( charger goes offlineand need to be wake up with Bluetooth connection), but the customer Support was extremely helpful and the last update correct the issue. Bought it at the end December ( was on special ) and used to charge my Ioniq 5. Until now, I'm very satisfied. Thanks Autel

Hi Valentin,

Thanks for sharing and we are glad you're happy with our EV Charger. Your trust and support are our greatest motivation to continue developing high-quality products and services.

Best regards,
Autel Team

m
moshiko peer
The Best One

wow design for 2025 :-)

Thank you! We're thrilled that you love the design . Your feedback means a lot to us!

D
Daniel Dufour Customer
Autel MaxiCharger AC Elite Home 50A EV Charger

I purchased the Autel MaxiCharger AC Elite Home 50A charging station and had it installed during the month of June 2024. After pairing it with the app on my cell phone, no network was detected. At first, I thought the terminal was defective, but after purchasing a Wifi range extender (Linksys RE7000), the terminal displayed several networks, including my own. I connected to my network and it worked. Since then, I've been using my app, and I have to say that it's really well designed and user-friendly. When I thought my charging point was faulty, I contacted Autel customer service and was really well served; I didn't wait long for someone to get back to me and the person was really courteous and kind. She was even willing to change my charging point, which I thought was faulty. Once my charging station was connected to my Wifi network, I called Autel's technical support team back to get some explanations on how to use the application, and they were very patient with me. I highly recommend this product. Thank you to the Autel staff for their warm welcome and service.

Thank you for your wonderful feedback! We're delighted to hear that you're satisfied with the Autel MaxiCharger and our customer service. Your recommendation means a lot to us. If you ever need further assistance, don't hesitate to reach out.

B
B. Just
Smart charger capable of 50amps

Perfect match for charging my VW ID4 PRO S at the maximum level 2 rate the VW ID4 can accept. Clean install, hardwired to 240 volts.

S
Serge
Facile d’installation

Je ne regrette pas mon achat, sauf que les instructions sont en anglais

Bonjour,

Je suis ravi d'apprendre que vous êtes content de votre achat. Je suis désolé d'entendre que les instructions n'étaient qu'en anglais. Nous avons en fait un manuel en français disponible en ligne. Vous pouvez le consulter ou le télécharger à partir du lien suivant : https://cdn.shopify.com/s/files/1/0770/0706/1312/files/MaxiCharger_AC_Elite_Residential__User_Manual_v2-FR.pdf?v=1712719604

Si vous avez d'autres questions ou besoins, n'hésitez pas à nous le faire savoir.

Cordialement,
Autel Energy

P
Paul Larn
Works great

Install was easy and straight forward. I did hire an electrician to do the install. I am an amateur electrician and after watching him do it. I am confident I could do it if I ever need to again. It looks nice, the cord is ample and the machine works great. The app is constantly improving and works great.

We appreciate your positive review! It's wonderful to know that you found the installation process easy and that you're satisfied with the performance of the machine as well as the app. Thanks for choosing our product!

AUTEL ENERGY

S
Serge Turcotte
Efficace

Excellent chargeur.
Puissance stable de 50A.
Look épuré et robuste.
Connexion wifi avec historique de charge pratique pour le suivi de consommation.

Hello Serge,

So happy to hear that you're satisfied and enjoying our charger!

Best regards,
Autel EV Chargers Official Website

D
Dayron
a great product

simply great, practical, easy to install and having all the information I need on my phone about consumption and the variety of options it offers is worth its price

D
Dheepak Jeevaraj
Pretty good EV charger

I got the hardwired version so I can use the full 11.5kw limit supported by most cars today.

The app and hardware are both done quite well. Installed the charger on my own without any issues - quite simple.

I like the ability to hard-limit to 48A instead of 50A, as I've a 60A breaker.

Definitely recommend this charger.

Thank you for the positive review and recommendation! We're very glad to hear that you're satisfied with our app and hardware and that the installation process was straightforward for you. Your support means a lot to us. Feel free to reach out if you have any other questions or need further assistance. Thanks again for your review!

Autel Energy

D
David L
Very good charger, app and great customers service!

I was worried by the original cable being too stiffed during cold weather, but the new one they are now offered has very improved! At -10C it’s still flexible 🙂

I’m using it to charge my Vinfast Vf8 car.
Thank you Autel!

Dear customer, we're thrilled to hear that you're satisfied with our charger, app, and customer service. We appreciate your feedback regarding the flexibility of the cable in cold weather. Thank you for choosing Autel to support your Vinfast Vf8 car charging needs.

D
David P.
Fast Charger.

50A charger makes this one of the faster level 2 you can install in your home. Just remember that your breaker should be rated for 125% of this amperage. But our car charges so much faster than our neighbors with Tesla level 2 chargers.

Thanks for the feedback! We're thrilled our 50A charger is working well for you. Safety and efficiency are our top priorities. Correct breaker rating is important for proper functioning. Keep enjoying the faster charging times!

Best, Team Autel Energy

T
TT
Red Dot Design Award

The design of the charger is impressive, and I am eagerly awaiting its installation by an electrician. I have included some photos of the internals in this review. Once I have had a chance to use the charger, I will provide an update. Many electricians and EV car manufacturers recommend hardwiring the charger. It's important to check with your local government as some places require a certified electrician for installation.

Thank you for your review! We're glad you appreciate the design of our charger. It's great to hear that you're being thorough with your installation process. We're keen to hear your thoughts once you've had a chance to use the charger. If you have any questions or need further assistance, feel free to reach out to us. Enjoy your EV charging experience!

Autel Energy

A
Adam P.
Good so far

Had this professionally installed. Looks good. It's mounted outdoors and seems sufficiently weatherproof.
Charges much faster than our level 1 trickle charger. The app is good and allows for timed charging based on the utilities' time of use rates.

Y
Yuriy M.
Fast charger

The best car charger. Fast level 2 charger. Long, 25 feet charging hose.
There was only one issue that it had to be connected to the Ethernet port for the firmware update after it was installed on the outside wall. So I had to run long Ethernet cable from my router to the charger. After the firmware was updated then I was able to connect the charger to the Wi-Fi.

Hello, thank you for your review on our EV charger! Regarding your experience with the Ethernet connection requirement for firmware updates, we want to clarify that our chargers are designed to offer more convenience. You shouldn't have needed to initially connect via Ethernet for updates. Instead, after installation, you can simply download our app to configure the network settings directly through Wi-Fi or Bluetooth, making updates hassle-free :)

N
Nick F
Does the job.

Nice long plug cord so it doesn’t matter which side of the driveway I park.
